🔧 Key Specifications
- Engine Power: 74 hp (Tier 4-compliant diesel)
- Rated Operating Capacity (ISO): 2,450 lbs
- Tipping Load: 7,000 lbs
- Operating Weight: 8,927 lbs
- Ground Pressure: 5.9 psi
- Auxiliary Hydraulic Flow:
- Standard: 17.6 gal/min
- High Flow: 26.9 gal/min
- Travel Speed:
- Standard: 7.2 mph
- Two-Speed Option: 10.2 mph
- Fuel Tank Capacity: 28.3 gallons
- Dimensions:
- Length with Standard Bucket: 134.9 in
- Width (without bucket): 67 in
- Height to Bucket Hinge Pin: 120 in
- Track Width: 12.6 in (optional 15.7 in)
- Reach at Maximum Height: 36.7 in
